Suzuki GSX-R 1000 Service Manual: Vehicle identification number
The frame serial number or V.I.N. (Vehicle identification number) “a” is stamped on the right side of the steering head tube. The engine serial number “b” is located on the lower crankcase. These numbers are required especially for registering the machine and ordering spare parts.
Vehicle side view
Note
difference between illustrations and actual
motorcycles may exist depending on the
markets.
Suzuki gsx-r1000 (2009-model)
Right side
Left side ...
Fuel and oil recommendation
Fuel (for USA and Canada)
Use only unleaded gasoline of at least 90 pump octane
(r/2 + m/2).
Gasoline containing mtbe (meltyl tertiary butyl ether),
less than 10% ethanol, or less than 5% methan ...
Other materials:
Camshaft sprocket
Inspect the camshaft sprocket in the following
procedures:
remove the intake and exhaust camshafts. Refer to “engine top side
disassembly” .
Inspect the teeth of each camshaft sprocket for wear
or damage.
If they are worn or damaged, replace the sprocket/
camshaft assembl ...
Schematic and routing diagram
Fuel tank drain hose and breather hose routing diagram
Fuel tank water drain hose
Fuel tank breather hose no. 1
Fuel tank breather hose no. 2
Fuel tank breather hose no. 3
3-Way joint
Frame
White marking
Set the
hose end to the root of tank nippl ...
Stp sensor removal and installation
Removal
Remove the throttle body. Refer to “throttle body
removal and installation” in section 1d (page 1d-
10).
Remove the stp sensor (1) with the special tool.
Special tool
: 09930–11950 (torx wrench (5 mm))
Note
prior to disassembly, mark the stp sensor’s
origina ...
